Cable chain
Vertical connector (connected to the midplane)
Horizontal connector (connected to the drive drawer)
The top cable chain is attached to drive drawer 1. The bottom cable chain is attached to drive drawer 5.
4. Use your finger to move the cable chain on the right side to the left.
5. Follow these steps to disconnect any of the right cable chains from its corresponding vertical bracket.
a. Using a flashlight, locate the orange ring on the end of the cable chain that is connected to the vertical
bracket in the enclosure.
17

NetApp DS460C Specifications

General

Model	DS460C
Category	Storage
Form Factor	4U
Drive Support	60 drives
Drive Types	SAS
Connectivity	12Gb/s SAS
Host Connectivity	SAS
RAID Support	RAID 6 (with NetApp storage controllers)
