If the output shows… Then…
All disk drives in the stack are connected through
path A and path B except for the ones in the disk
shelves you disconnected, which are only
connected through path B
Go to the next step.
You successfully bypassed the disk shelves you are
removing and reestablished path A on the
remaining disk drives in the stack.
Anything other than the above Repeat Step 5 and Step 6.
You must correct the cabling.
8. Complete the following substeps for the disk shelves (in the stack) you are removing:
a. Repeat Step 5 through Step 7 for path B.
When you repeat Step 7 and if you have recabled the stack correctly, you should only
see all remaining disk drives connected through path A and path B.
b. Repeat Step 1 to confirm that your system configuration is the same as before you removed one or
more disk shelves from a stack.
c. Go to the next step.
9. If when you removed ownership from the disk drives (as part of the preparation for this procedure), you
disabled disk ownership automatic assignment, reenable it by entering the following command; otherwise,
go to the next step:
storage disk option modify -autoassign on
For HA pair configurations, you run the command from the clustershell of both controllers.
10. Power off the disk shelves you disconnected and unplug the power cords from the disk shelves.
11. Remove the disk shelves from the rack or cabinet.
To make a disk shelf lighter and easier to maneuver, remove the power supplies and I/O modules (IOMs).
For DS460C disk shelves, a fully loaded shelf can weigh approximately 247 lbs (112 kg); therefore,
exercise the following caution when removing a shelf from a rack or cabinet.
It is recommended that you use a mechanized lift or four people using the lift handles to
safely move a DS460C shelf.
Your DS460C shipment was packaged with four detachable lift handles (two for each side). To use the lift
handles, you install them by inserting the tabs of the handles into the slots in the side of the shelf and
pushing up until they click into place. Then, as you slide the disk shelf onto the rails, you detach one set of
handles at a time using the thumb latch. The following illustration shows how to attach a lift handle.
40
