NetApp FAS500f - Page 760

1
Controller module cover locking button
3. Align the end of the controller module with the opening in the chassis, and then gently push the controller
module halfway into the system.
<div class="aspect-ratio"><iframe frameborder="1" height="400"
scrolling="auto"
src="https://netapp.hosted.panopto.com/Panopto/Pages/embed.aspx?id=f2aa1
4b4-0d95-4109-b410-ae78004b35c9" width="711"> </iframe></div>
Animation - Install controller
A1
B1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A
B
2
1
758
