NetComm NL1901ACV Quick Start Guide

6
1. Connect the supplied RJ11 cable to the “modem” port of your DSL line lter and then connect the other end to
the DSL port on the back of the NL1901ACV. Connect the DSL line lter (not included) to the wall socket.
2. Connect the supplied RJ45 Ethernet cable from one of the yellow Ethernet ports (1-4) on the back of the
NL1901ACV to your computer.
3. If you intend to use a cellular connection as a backup, insert a SIM card (in 2FF format) in the direction shown
in the diagram on the next page, then attach the 4G/LTE antennas by turning them in a clockwise direction
on the antenna sockets, as shown in the diagram on the next page.
4. Connect the included power adapter to the Power jack of the NL1901ACV and then plug it into an available
wall socket. Press the ON/OFF button to power the router on. The Power light illuminates in red. When the
NL1901ACV has nished booting up, the Power light turns green.
SETTING UP YOUR
GATEWAY
VDSL Connections

NetComm NL1901ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
Product type	Tabletop router
Product color	Black
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
4G LTE category	8
Mobile network generation	4G
Output current	2 A
Output voltage	12 V
Power source type	AC
Memory card slot(s)	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK

Weight and Dimensions

Depth	75 mm
Width	230 mm
Height	200 mm
Weight	562 g
