NetComm NL1901ACV Setup Guide

NL1901ACV – Wireless Security Setup Guide
5 of 7
FQ001125 v. 1.1 March 2019
© NetComm Wireless 2019
Connecting to your Wireless Network
Use your client device to scan for the network name, select the new WiFi network name/SSID (e.g. NetComm 8386)
and enter the new WiFi password to join the network.
Windows 10
The following is an example of connecting to the WiFi network using Windows 10.
1 Click the wireless symbol in the bottom right corner of the device. A list of detected networks within range of
your computer is displayed. Select your WiFi network name (In this example, it is “NetComm 8386”) and click
Connect.
2 Enter the WiFi security key/password and click
Next.
3 Your computer connects to the WiFi network.
If you are facing difficulty to connect the Wi-Fi network name, refer to “Wireless Troubleshooting Guide”
from FAQs section.

NetComm NL1901ACV Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
Product type	Tabletop router
Product color	Black
Networking standards	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
4G LTE category	8
Mobile network generation	4G
Output current	2 A
Output voltage	12 V
Power source type	AC
Memory card slot(s)	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 95 %
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK

Weight and Dimensions

Depth	75 mm
Width	230 mm
Height	200 mm
Weight	562 g
