NETGEAR AC1200 User Manual

5
If NETGEAR genie Does Not Display
• Make sure that the computer is connected to one of the four LAN
Ethernet ports, or wirelessly to the router.
• Make sure that the router has full pow
er, and that its WiFi LED is
solid blue.
• To make sure that the browser does not cache the previous page,
close an
d reopen the browser. Then type www.routerlogin.net.
• If the computer is set to a static or fixed IP address (this condition
is uncom
mon), change it to obtain an IP address automatically
from the router.
Preset Wireless Security
This product has a uniqu e WiFi network name (SSID) and network
key (password). The default SSID and password are uniquely
generated for every device, like a serial number, to protect and
maximize your wireless security. This information is on the label on
the bottom of the product.

NETGEAR AC1200 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	900 Mbit/s
Internal	No
Minimum system requirements	Intel Pentium class PC Available USB 1.1, USB 2.0, or USB 3.0 port Microsoft Windows 7, XP, Vista: (32/64-bit) Supports Windows 8
Cables included	USB
Interface	WLAN
USB version	2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A
Connectivity technology	Wireless
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rates supported	300, 867 Mbit/s
Quantity	1
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	93 mm
Width	31.4 mm
Height	14.45 mm
Weight	28 g
