NETGEAR C7100V

Voice Telephone Lines
65
AC1900 Cable Modem Voice Router
Connect a Telephone Line
 To connect a telephone line:
1. Connect one end of the phone cable to the Tel (Voice) port on the rear panel of the
modem router.
Phone cable
2. Connect the other end of the phone cable to the telephone.
3. Call
Comcast XFINITY customer service at 1-800-XFINITY (1-800-934-6489) and ask
them to register the phone lines.
The Tel (Voice) LED blinks while the phone is being registered and
then lights solid white.
After the voice line is registered, you can hear a dial tone when the phone is of
f-hook.
View the Voice Status
 To view the voice status:
1. Launch
a web browser from a computer or mobile device that is connected to the
network.
2. T
ype http://routerlogin.net or http://192.168.0.1.
A login window opens.
3. Enter
the modem router user name and password.
The user name is admin.
The default password is password. The user name and
password are case-sensitive.
The BASIC Home page displays.
