Technical Specifications A-1
v1.3, March 2007
Appendix A
Technical Specifications
This appendix provides technical specifications for the 54 Mbps ADSL Modem Wireless Router
Model DG834G.
Network Protocol and Standards Compatibility
Data and Routing Protocols: TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPPoA, or PPTP, RFC 1483
Bridged or Routed Ethernet, and RFC 1577 Classical IP over ATM
Power Adapter
North America: 120V AC, 60 Hz, input
United Kingdom, Australia: 240V AC, 50 Hz, input
Europe: 230V AC, 50 Hz, input
Japan: 100V AC, 50/60 Hz, input
All regions (output): 12 V DC @ 1.0A output
Physical Specifications
Dimensions: 6.9" x 4.7" x 1.1"
175 mm x 119 mm x 28 mm
Weight: 0.7 lbs.
0.3 kg
Environmental Specifications
Operating temperature: 0° to 40° C (32º to 104º F)
Operating humidity: 90% maximum relative humidity, noncondensing
Electromagnetic Emissions
Meets requirements of: FCC Part 15 Class B; VCCI Class B; EN 55 022 (CISPR 22), Class B
Interface Specifications
LAN: 10BASE-T or 100BASE-Tx, RJ-45
WAN: ADSL, ADSL2+, Dual RJ-11, pins 2 and 3,T1.413, G.DMT, G.Lite, ITU
Annex A (for the DG834G) or ITU Annex B (for the DG834GB)
