DG834N RangeMax NEXT Wireless ADSL2+ Modem Router Reference Manual
4-6 Managing Your Network
v1.0, April 2008
ADSL Port These settings apply to the Internet (ADSL) port of the modem router.
MAC Address This field displays the Ethernet MAC address being used by the Internet
(ADSL) port of the modem router.
IP Address This field displays the IP address being used by the Internet (ADSL) port
of the modem router. If no address is shown, the modem router cannot
connect to the Internet.
Network Type The network type depends upon your ISP.
IP Subnet Mask This field displays the IP subnet mask being used by the Internet (ADSL)
port of the modem router.
Gateway IP Address IP address used as a gateway to the Internet for computers configured to
use DHCP.
Domain Name Server (DNS) This field displays the DNS server IP addresses being used by the
modem router. These addresses are usually obtained dynamically from
the ISP.
LAN Port These settings apply to the local (ADSL) port of the modem router.
MAC Address This field displays the Ethernet MAC address being used by the local
(LAN) port of the modem router.
IP Address This field displays the IP address being used by the local (LAN) port of
the modem router. The default is 192.168.0.1.
DHCP If Off, the modem router does not assign IP addresses to PCs on the
LAN.
If On, the modem router does assign IP addresses to PCs on the LAN.
IP Subnet Mask This field displays the IP subnet mask being used by the local (LAN) port
of the modem router. The default is 255.255.255.0.
Modem These settings apply to the local (WAN) port of the modem router.
ADSL Firmware Version The version of the firmware.
Modem Status The connection status of the modem.
Downstream Connection
Speed
The speed at which the modem is receiving data from the ADSL line.
Upstream Connection Speed The speed at which the modem is transmitting data to the ADSL line.
VPI The Virtual Path Identifier setting.
VCI The Virtual Channel Identifier setting.
Wireless Port These are the settings as specified n the Wireless Settings screen; see
“Understanding Wireless Settings” in Chapter 2 for details.
Name (SSID) The service set ID, also known as the wireless network name.
Table 4-1. Router Status Fields (continued)
Field Description
