Getting to Know Your Wireless Router 2
Hardware Features
Before you install and connect your router, take a moment to become familiar with the front and
back panels of the router—especially the LEDs on the front panel.
Router Front Panel
The wireless modem router front panel shown below contains status LEDs.
Figure 1
Power
LAN Ports (1-4)
DSL
Internet
Wireless
WPS
