NETGEAR EX2700 User Manual

Extender Network Settings
19
N300 WiF Range Extender
5. Select Settings > WiFi.
6. Clear the Broadcast the Network name (SSID) check box.
7. Click the SA
VE button.
Your settings are saved.
Disable or Enable the WiFi Radio
By default, the extender’s WiFi radio broadcasts signals in the 2.4 GHz band. If you disable
the WiFi radios, then no one can connect with WiFi to the extender.
 To disable or enable the WiFi radio:
1. On a computer or WiFi device that is connected to the extender network, launch a web
browser
.
2. In the address field of your browser
, enter www.mywifiext.net.
3. When prompted, enter your email address and password.
The Status page displays.
4. If your browser displays the Menu icon
, click it.
The extender menu displays.

NETGEAR EX2700 Specifications

General

Type	Network repeater
Maximum transfer distance	- m
External power adapter	No
On/off switch	Yes
Product color	White
LED indicators	Power, WPS
Antennas quantity	2
Bandwidth	2.4 GHz
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA, WPA2-PSK
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	34 mm
Width	55 mm
Height	67 mm
Weight	98 g
