Get Started
11
AC1200 WiF Range Extender
To use WPS to connect the extender to your WiFi router:
1. Press the WPS button on the extender.
The WPS LED
blinks.
2. Within two minutes, press the WPS button on your router or access point.
The WPS LED on the extender lights solid green, the Router Link LED
lights, and
the extender connects to your existing WiFi network.
If the Router Link LED does not light, try again. If it still does not light, see Connect With
the NETGEAR Installation Assistant on page 12.
3. If your WiFi router supports the 5 GHz band, repeat Steps 1 and 2 to connect the extender
to the 5 GHz band.
4. Unplug the extender and move it to a new location that is about halfway between your router
and the area with a poor router WiFi signal.
The location that you choose must be within the range of your existing WiFi router
network.
DO DON’T
5. Plug the extender into an electrical outlet and wait for the Power LED to light green.
6. Use the Router Link LED
to help you choose a spot where the extender-to-router
connection is optimal.
7. If the Router Link LED doesn’t light amber or green, plug the extender into an outlet closer
to the router and try again.
Keep moving the extender to outlets closer to the router until the Router Link LED lights
amber or green.
8. On your WiFi-enabled computer or mobile device, open the WiFi connection manager and
locate and connect to the new extender WiFi network.
The extender creates two new extender WiFi networks. The extender’s new WiFi network
names are based on your existing WiFi network name, with _2GEXT and _5GEXT at the
ends of the names.
For example:
• Existing W
iFi network name. MyNetworkName
• New extender W
iFi network names. MyNetworkName_2GEXT and
MyNetworkName_5GEXT
Use the same WiFi password that you use for your WiFi router.
