FS728TP Smart Switch Software Administration Manual
6-20 Managing Security
v1.1, September 2009
“IPv6 ACL”
“IPv6 Rules”
“IPv6 Binding Configuration
“Binding Table”
MAC ACL
The MAC Configuration screen allows a MAC Based ACL to be defined.
To view or rename MAC Based ACLs:
1. Click Security > ACL > MAC ACL. The MAC Configuration screen displays:
The MAC Configuration screen contains the following fields:
MAC ACL
Current number of ACL – Displays the current number of user-defined ACLs.
MAC ACL Table
Name – Enter the user-defined MAC based ACL name.
Figure 6-9

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR FS728TP and is the answer not in the manual?

NETGEAR FS728TP Specifications

General IconGeneral
MAC address table8000 entries
Store-and-forwardYes
Packet buffer memory3 MB
Maximum data transfer rate1 Gbit/s
Number of VLANs128
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Latency20 μs
Dimensions (WxDxH)440 x 257 x 43 mm
Power requirements100 - 240 VAC, 50 - 60 Hz
Authentication methodIEEE 802.1x
Connectivity technologyWired
DHCP featuresDHCP client
Switch typeManaged
Power connectorDC-in jack
SFP/SFP+ slots quantity2
Gigabit Ethernet (copper) ports quantity4
Basic switching RJ-45 Ethernet ports quantity24
StackableNo
CertificationCE mark FCC Part 15 Class A VCCI Class A C-Tick EN 55024 cUL IEC 950/EN 60950
Noise level49 dB
Mean time between failures (MTBF)176000 h
Power consumption (typical)225 W
Operating altitude0 - 3000 m
Storage temperature (T-T)-20 - 70 °C
Operating temperature (T-T)0 - 50 °C
Storage relative humidity (H-H)0 - 95 %
Operating relative humidity (H-H)0 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight3600 g
