NETGEAR FS728TP User Manual

FS728TP Smart Switch Software Administration Manual
7-10 Monitoring the Switch
v1.1, September 2009
6. Enter an optional server Description in the provided field in the first row.
7. Select the Minimum Severity level message sent to the server from the list in the provided
field in the first row.
8. Click APPLY to update the device.
To add a remote log server:
1. Click Monitoring > Logs > Server Log. The Server Log screen displays.
2. Enter the Server IP address in the provided field in the first row.
3. Enter the UDP Port number in the provided field in the first row.
4. Select the Facility assigned to the server from the list in the provided field in the first row.
5. Enter an optional server Description in the provided field in the first row.
6. Select the Minimum Severity level message sent to the server from the list in the provided
field in the first row.
7. Click ADD to update the device.
To remove a remote log server:
1. Click Monitoring > Logs > Server Log. The Server Log screen displays.
2. Select the log server entry.
3. Click DELETE to remove the log server entry.
RMON
This section contains information for viewing Remote Monitoring Statistics. RMON Statistics
allow network managers to view network traffic information from a single workstation.
The RMON menu contains the following options:
• “Basic”
• “Advanced”
Basic
The RMON Basic menu contains the following options:
• “Statistics”

NETGEAR FS728TP Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Packet buffer memory	3 MB
Maximum data transfer rate	1 Gbit/s
Number of VLANs	128
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Latency	20 μs
Dimensions (WxDxH)	440 x 257 x 43 mm
Power requirements	100 - 240 VAC, 50 - 60 Hz
Authentication method	IEEE 802.1x
Connectivity technology	Wired
DHCP features	DHCP client
Switch type	Managed
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Gigabit Ethernet (copper) ports quantity	4
Basic switching RJ-45 Ethernet ports quantity	24
Stackable	No
Certification	CE mark FCC Part 15 Class A VCCI Class A C-Tick EN 55024 cUL IEC 950/EN 60950
Noise level	49 dB
Mean time between failures (MTBF)	176000 h
Power consumption (typical)	225 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %

Weight and Dimensions

Weight	3600 g
