Hardware Setup
11
N300 Wireless Gigabit Router with USB JNR3210
Back Panel
The back panel has the connections shown in the following figure.
USB
Ethernet LAN
Internet
Power
Reset
On/Off button
Figure 3. Router, rear view
See Factory Default Settings on page 118 for information about restoring factory settings.
Label
The label on the bottom of the router shows the WPS PIN, login information, MAC address,
and serial number.
MAC address
Serial number
WPS Security
PIN
Figure 4. The label shows unique information about your router
