Advanced Settings
86
N300 Wireless Gigabit Router with USB JNR3210
Wireless Repeating Function (WDS)
You can set the N300 Wireless Gigabit Router with USB up to be used as a wireless access
point (AP). Doing this enables the router to act as a wireless repeater. A wireless repeater
connects to another wireless router as a client where the network to which it connects
becomes the ISP service.
Wireless repeating is a type of Wireless Distribution System (WDS). A WDS allows a wireless
network to be expanded through multiple access points instead of using a wired backbone to
link them. The following figure shows a wireless repeating scenario.
Repeater
Base station
access point
access point
Figure 8. Wireless repeating scenario
Note: If you use the wireless repeating function, you need to select either
WEP or None as a security option in the Wireless Settings screen.
The WEP option displays only if you select the wireless mode Up to
54 Mbps in the Wireless Settings screen.
Wireless Base Station. The router acts as the parent access point, bridging traffic to and
from the child repeater access point, as well as handling wireless and wired local computers.
