NETGEAR Nighthawk X4S

• Base of a cordless phone
• 2.4 GHz cordless phone
• Place the router away from large metal surfaces, large glass surfaces, insulated walls, and items such as these:
• Solid metal door
• Aluminum studs
• Fish tanks
• Mirrors
• Brick
• Concrete
Cable Your Router
The following image shows how to cable your router:
Figure 6. Router cabling
To cable your router:
1. Unplug your modem’s power, leaving the modem connected to the wall jack for your Internet service.
If your modem uses a battery backup, remove the battery.
2. Plug in and turn on your modem.
If your modem uses a battery backup, put the battery back in.
Hardware Setup
15
Nighthawk X4S AC2600 Smart WiFi Router
