Button Descriptions
Use the buttons to restore the adapter to the factory configuration and to create a secure PowerLINE network.
Table 2. Button descriptions
DescriptionButton or Switch
Press the Factory Reset button for one second, and then release it to return the PowerLINE
adapter to its factory default settings.
Factory Reset
Use the Security button to create a secure PowerLINE network.Security
Use the WPS button to automatically connect your computer or other WiFi devices that support
WPS to your PowerLINE network.
WPS (PLW models only)
Use the On/Off switch to turn the device on and off.On/Off (PLW models only)
Ethernet Port
PowerLINE adapters use an Ethernet port to convert a standard electrical wall outlet into a high-speed wired
network connection.You can use the wired network connection to bring Internet connectivity to any device
with an Ethernet port, such as a computer, game console, Blu-ray player, smart TV, HD set-top box, or
network DVR.
Extra Outlet
For models with an extra outlet, you must observe a few restrictions on how you use the extra outlet.
The technical specifications for your model provide socket outlet ratings. See Technical Specifications and
Safety Information on page 25. See Safety Information on page 33 for general guidelines for use.
Adapter Label
The adapter label provides unique details specific to your device. It displays the following:
• Model number
• PowerLINE MAC address (except PL1000, PL1010, PLP1000)
• Ethernet MAC address (except PL1000, PL1010, PLP1000)
• MAC address (PL1000, PL1010, PLP1000 only)
• Serial number
• Device password
Your PowerLINE Adapter
13
