PowerLINE PL1000 and PL1010 Technical Specifications
The PL1000 and PL1010 adapters meet the technical specifications defined in the following table.
Table 3.Technical specifications
SpecificationFeature
IEEE 802.3 (10BASE-T), IEEE 802.3u
(100BASE-T), IEEE 802.3ab
(1000BASE-T)
Data and routing protocols
100–240V, 0.1A (max.)AC input
AU: 10A, 250V; EU: 16A, 250V; NA: 15A,
125V; UK: 13A, 250V
Socket-outlet rating (max. load)
Normal: < 3.73W; Power saving mode: <
0.5W
Power consumption
100 x 59 x 35.9 mm (3.9 x 2.3 x 1.4 in.)Dimensions
126 g (0.28 lb)Weight
0° to 40°C (32º to 104ºF)Operating temperature
10–90% maximum relative humidity,
noncondensing
Operating humidity
5–95% maximum relative humidity,
noncondensing
Storage humidity
128-bit AESSecurity encryption type
8 (active), 8 (total): number of nodes that
can be added to a single network
MAC addresses
1000 MbpsBandwidth
Up to 1000 Mbps with real throughput
greater than 80 Mbps
Data transfer rate
2–86 MHzFrequency band
OFDM windowed modulationModulation type
Technical Specifications and Safety Information
26
