PowerLINE PL1000v2 and PL1010v2 Technical
Specifications
The PL1000v2 and PL1010v2 adapter meets the technical specifications defined in the following table.
Table 4.Technical specifications
SpecificationFeature
IEEE 802.3 (10BASE-T), IEEE 802.3u
(100BASE-T), IEEE 802.3ab
(1000BASE-T)
Data and routing protocols
100–240V, 0.1A (max.)AC input
AU: 10A, 250V; EU: 16A, 250V; NA: 15A,
125V; UK: 13A, 250V
Socket-outlet rating (max. load)
Normal: < 3.73W; Power saving mode:
< 0.5W
Power consumption
100 x 59 x 35.9 mm (3.9 x 2.3 x 1.4 in.)Dimensions
Varies by region. About 126 g (0.28 lb)Weight
0° to 40°C (32º to 104ºF)Operating temperature
10–90% maximum relative humidity,
noncondensing
Operating humidity
5–95% maximum relative humidity,
noncondensing
Storage humidity
128-bit AESSecurity encryption type
8 (active), 8 (total): number of nodes that
can be added to a single network
MAC addresses
1000 MbpsBandwidth
Up to 1000 Mbps with real throughput
greater than 80 Mbps
Data transfer rate
2–86 MHzFrequency band
4096/1024/256/64/16/8-QAMModulation type
Technical Specifications and Safety Information
27
