NETGEAR ProSafe GS110TP User Manual

1-1
v1.0, March 2010
Chapter 1
Introduction
Congratulations on the purchase of your NETGEAR GS110TP Smart PoE Switch. The GS110TP
Smart PoE Switch is a supplement to the Gigabit Advanced Smart Switch family. Available as a
desktop or wall-mountable switch, the GS110TP Smart PoE Switch is not intended to be rack-
mountable. The GS110TP is a PoE-supportable, low-port switch with two fiber uplinks included.
This chapter serves as an introduction to the GS110TP Smart PoE Switch and provides the
following information:
• Overview
• Features
• Package Contents
Overview
This Installation Guide is for the NETGEAR GS110TP Smart PoE Switch. This product offers
support for eight 10/100/1000 Mbps autosensing and two 1000M SFP Gigabit Ethernet switching
ports.
Using Gigabit ports, high-speed connections can be made to a server or network backbone. For
example:
• Linking to high-speed servers
• Providing 10/100/1000 Mbps copper connectivity
The GS110TP Smart PoE Switch also provides the benefit of administrative management with a
complete package of features for the observation, configuration, and control of the network. With a
Web-based Graphical User Interface (GUI), the switch’s many capabilities can be viewed and used
in a simple and intuitive manner. The switch’s management features include configuration for port
and switch information, VLAN for traffic control, port trunking for increased bandwidth, and
Class of Service (CoS) for traffic prioritization. These features provide better understanding and
control of the network. Initial discovery of the switch on the network requires the Netgear Smart
Control Center program, a utility that runs on a PC.

NETGEAR ProSafe GS110TP Specifications

General

MAC address table	4000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10/100/1000 Mbps
10G support	No
Number of VLANs	64
Networking standards	IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	1000BASE-TX, 100BASE-TX, 10BASE-T
Latency	4 μs
Dimensions (WxDxH)	236 x 101.6 x 27 mm
Networking features	Gigabit Ethernet
DHCP features	DHCP client
Switch type	Managed
Switch layer	-
Power connector	DC-in jack
SFP/SFP+ slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	8
Safety	cUL IEC 950/EN 60950, CB, CE
Certification	CE mark, FCC Part 15 Class A, VCCI Class A, C-Tick
LED indicators	LAN, Status
Power source	48v, 1.25A
Power consumption (typical)	59.3 W
Mean time between failures (MTBF)	157004 h
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	700 g
