Manage Your WiFi Network
24
NETGEAR genie App
5. Enter your router’s admin password and tap the LOGIN button.
The dashboard displays.
6. T
ap WiFi.
The QR code displays.
Scan a WiFi Network QR Code Using the Mobile genie
App
The Android and iOS mobile genie app includes a QR scanner so that you can scan a WiFi
network QR code that displays on another device so that your device can join the WiFi
network.
To connect to a WiFi network using the QR code scanner on the genie mobile app:
1. Connect your mobile device to the router
’s WiFi network.
Note: If you’re accessing your router remotely, skip this step.
2. Launch the genie mobile app
.
3. T
ap SKIP.
If you’re accessing your router locally, the Local Access page displays. If you’re
accessing your router remotely
, the Remote Access page displays.
4. Tap CONTINUE WITHOUT LOGIN.
The dashboard displays.
5. T
ap QR Scanner.
6. If you did not allow the genie mobile app to access your camera, tap the OK button to allow
access.
7. When prompted, align the QR code within the frame.
Your phone or tablet scans the QR code for the network.
If you are using an iOS device, the password is copied to the clipboard.
If you are using an Android device, a pop-up message displays asking if you want to
connect to the network.
8. If you are using an iOS device, do the following:
a. Exit the app.
b. T
ap Settings > Wi-Fi.
c. T
ap the network name.
d. Paste the password from the clipboard in the Password field.
e. T
ap Join.

Table of Contents

Other manuals for NETGEAR R6120

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR R6120 and is the answer not in the manual?

NETGEAR R6120 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)1200 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)900 Mbit/s
Product typeTabletop router
Product colorBlack
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Memory card slot(s)-
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Power source typeAC
Antennas quantity2
Cables includedLAN (RJ-45)
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Security algorithmsWPA, WPA2-PSK
Package depth219 mm
Package width179 mm
Package height109 mm
Package weight660 g
Shipping (inner) case width461 mm
Shipping (inner) case height215 mm
Shipping (inner) case length352 mm
Shipping (inner) case net weight4780 g
Number of layers per pallet (sea)9 pc(s)
Number of cartons per pallet layer6 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth136.5 mm
Width185 mm
Height46 mm
Weight250 g
