NETGEAR RAXE500 User Manual

Top panel LEDs and buttons
The status LEDs and two buttons are located on the top panel of the router.
Figure 2. Top view
Table 1. LED descriptions
DescriptionLED and Button
Solid white. The router is ready.
Blinking white. The router is not ready, firmware is upgrading, or the Reset
button was pressed.
Off. Power is not supplied to the router.
Power LED
Solid white. The Internet connection is ready.
Blinking white. The port is sending or receiving traffic.
Off. No Ethernet cable is connected between the router and the modem.
Internet LED
User Manual10Hardware Setup
Nighthawk AXE11000 Tri-Band WiFi 6E Router

NETGEAR RAXE500 Specifications

General

WiFi Speeds	Up to 10.8Gbps
WiFi Bands	Tri-Band
2.4GHz Band Speed	Up to 1.2Gbps
5GHz Band Speed	Up to 4.8Gbps
6GHz Band Speed	Up to 4.8Gbps
Processor	1.8GHz Quad-Core Processor
Beamforming Technology	Yes
MU-MIMO	Yes
OFDMA	Yes
WiFi Technology	802.11ax
Memory	512MB NAND Flash and 1GB RAM
Ethernet Ports	1 x 2.5Gbps WAN, 4 x 1Gbps LAN
USB Ports	2 x USB 3.0
Antenna	8 high-performance internal antennas
Security	WPA3, VPN support
Weight	2.86 lb (1.3 kg)
