NETGEAR RAXE500 User Manual

Table 1. LED descriptions (Continued)
DescriptionLED and Button
Solid white. A USB device is connected to USB 3.0 port 2 and is ready.
Blinking white. A USB device is plugged in to USB 3.0 port 2 and is trying to
connect.
Off. No USB device is connected, or someone clicked the Safely Remove
Hardware button and it is now safe to remove the attached USB device.
USB 3.0 port 2 LED
Pressing the WiFi button for two seconds turns WiFi LED and WiFi radios on
and off.
If this LED is lit, the WiFi radios are on. If this LED is off, the WiFi radios are turned
off and you cannot use WiFi to connect to the router.
WiFi LED
Pressing the WPS button lets your WPS-enabled device join your router's WiFi
network without typing the WiFi password. The WPS LED blinks white during
the WPS process and then lights solid white when the WPS-enabled device
connects to your router's WiFi network.
WPS LED
Note: If the LED On/Off switch on the rear panel is moved to the Off position, all the
LEDs except the Power LED are turned off.
User Manual12Hardware Setup
Nighthawk AXE11000 Tri-Band WiFi 6E Router

NETGEAR RAXE500 Specifications

General

WiFi Speeds	Up to 10.8Gbps
WiFi Bands	Tri-Band
2.4GHz Band Speed	Up to 1.2Gbps
5GHz Band Speed	Up to 4.8Gbps
6GHz Band Speed	Up to 4.8Gbps
Processor	1.8GHz Quad-Core Processor
Beamforming Technology	Yes
MU-MIMO	Yes
OFDMA	Yes
WiFi Technology	802.11ax
Memory	512MB NAND Flash and 1GB RAM
Ethernet Ports	1 x 2.5Gbps WAN, 4 x 1Gbps LAN
USB Ports	2 x USB 3.0
Antenna	8 high-performance internal antennas
Security	WPA3, VPN support
Weight	2.86 lb (1.3 kg)
