Get Started
14
N300 WiF Range Extender
Connect Ethernet-Enabled Devices
After the extender is connected to your existing WiFi network, you can connect wired devices
to the extender using Ethernet cables. The devices can then access your existing network
through the extender’s WiFi connection.
Extender
WFi router
Blu-ray player
TV
Gaming console
Figure 4. Ethernet LAN port
Use the Extender in Access Point Mode
You can use the extender as a WiFi access point, which creates a new WiFi hotspot by using
a wired Ethernet connection.
Extender
iFi router
Figure 5. Extender in access point mode
To use the extender in access point mode:
1. Plug the extender into an electrical outlet.
2. W
ait for the Status LED to light amber and then turn green.
