NETGEAR XAV1301v1/XAVB1301v1 User Manual

Powerline Utility
14
Powerline AV 200 Mini Adapter XAV1301
Set the Powerline Encryption Key
Powerline devices that share the same Powerline network have to use the same encryption
key. The factory default encryption key is HomePlugAV.
In locations such as apartment buildings or office buildings, others might share the same
electrical power lines that you use for your Powerline network. To protect your Powerline
network from unwanted access, you can customize the encryption key for your Powerline
devices. Make sure that you set up exactly the same encryption key for all of your Powerline
devices so that they can communicate with each other.
You use the Security screen in the Powerline Utility to set encryption keys. If you customize
the encryption key and then forget what it is, you can return your Powerline devices to their
factory default Powerline encryption key of HomePlugAV.
 To set the encryption key:
1. Click the Powerline device icon or the Security icon
on the Powerline Utility main
screen.
The top section of the Security screen shows information about each device that the
Powerline Utility detects.
• Device Name. This lists the Powerline devices detected on the network after the
utility completes a scan for devices. The device name is initially set by the utility, but
you can change it to a descriptive name such as Office or Master Bedroom.
• Model. This identifies the model number of the Powerline adapter.
• MAC Address. The MAC address for the Powerline device. This is also on the
product label, which might not be visible when the device is plugged in.
• Device Password. To change settings for a remote Powerline device you have to
enter its password. The device password is located on the product label.
2. Select the check box for each device for which you want to set the encryption key.

NETGEAR XAV1301v1/XAVB1301v1 Specifications

General

Data and routing protocols	IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
Security encryption type	128-bit AES
MAC addresses	64: number of nodes that can be added to a single network
Frequency band:	2 -30Mbps
Modulation type:	OFDM symbol modulation
AC input	100-240V~, 0.1A (Max)
Power consumption	Normal: 3.5 W, Power saving mode: <1W
Operating temperature	0 ° to 40° C (32º to 104º F)
Operating humidity	10–90% maximum relative humidity, noncondensing
Storage humidity	5–95% maximum relative humidity, noncondensing
Electromagnetic emissions:	FCC Part 15 Class B; CE-EMC Class B; 3-home FCC Certificate
Safety agency approvals:	U L Listed (UL1950) /cUL IEC950; CE LVD; TUV CB, TUV GS
Bandwidth	2 00Mbps
Data transfer rate	U p to 200M bps with real throughput greater than 80Mbps
Compatibility	Not HomePlug v1.0 or HomePlug v1.0 Turbo compatible

Weight and Dimensions

Dimensions	90 x 53 x 32 mm (3.54 x 2.09 x 1.25 in)
Weight	0.119 kg (0.26 lb)
