Appendix A. Supplemental Information | 24
A
A. Supplemental Information
This appendix provides technical specifications and safety information for the XAV1601
Powerline AV+ 200 Nano.
Technical Specifications
Network Protocol and Standards Compatibility
Data and routing protocols: IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
AC input 100–240V~, 0.1A (Max)
Power consumption: 3W
Dimensions: Height: 105 mm
Width: 58 mm
Depth: 41 mm
Weight: 0.4 lbs (0.189 kg)
Environmental Specifications
Operating temperature: 0° to 40° C (32º to 104º F)
Operating humidity: 10–90% maximum relative humidity, noncondensing
Storage humidity 5–95% maximum relative humidity, noncondensing
Security
Encryption type: 128-bit AES
Bridge Performance
MAC addresses: 64
Powerline Performance
Compatibility: HomePlug AV
Data Transfer Rate: Up to 200 Mbps PHY rate or 90 Mbps data transfer rate
Frequency band: 2 – 30 MHz
