Chapter 1. Installation and Basic Configuration | 5
XAV1601 Powerline AV+ 200 Nano User Manual
Powerline XAV1601 Nano Features
The following illustration shows the front and bottom panels of the XAV1601:
Security
button
Factory
Reset
button
Filtered
AC Socket
Ethernet
port
Power
LED
Ethernet
LED
Powerline
LED
Figure 2. XAV1601 Powerline AV+ 200 Nano
XAV1601 Product Label
The product label on the rear panel of the XAV1601 contains the items listed below:
• Model number
• MAC address
• Device password
• Serial number
LED and Feature Descriptions
The following table describes the buttons, status LEDs, and Ethernet port on the XAV1601
Powerline AV+ 200 Nano.
