Appendix A. Supplementary Information | 22
A
A. Supplementary Information
Technical Specifications
Specification Description
Data and routing protocols IEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-Tx)
AC input 100-240V~, 0.2A (Max)
Power consumption 4W
Dimensions Height: 98 mm
Width: 72 mm
Depth: 40 mm
Weight 0.4 lbs (0.18 kg)
Operating temperature 0 to 40 C (32º to 104º F)
Operating humidity 10-90% maximum relative humidity, noncondensing
Storage humidity 5-95% maximum relative humidity, noncondensing
Encryption type 128-bit AES
MAC addresses 64: number of nodes that can be added as a single network
Bandwidth 200 Mbps
Compatibility HomePlug AV
Data transfer rate Up to 200 Mbps with real throughput greater than 80 Mbps
Frequency band 2-30 Mbps
Modulation type OFDM symbol modulation
Meets requirements of FCC Part 15 Class B; CE-EMC Class B; 3-home FCC certificate;
HomePlug
Meets requirements of UL Listed (UL 1950) /cUL IEC950; CE LVD; TUV CB; GS
