Getting Started
6
Powerline PassThru Adapter
Hardware Features
This section describes the hardware features of the Powerline PassThru adapters. Adapters
vary by region. Your adapter might look different.
XAV2602 Powerline 200 Nano PassThru Two-Port Adapter
The hardware features of the XAV2602 adapter are shown in the following figure.
Ethernet ports
Security
button
Factory Reset
button
Power
LED
Ethernet
LED
Powerline
LED
Filtered AC
socket
Figure 1. XAV2602 hardware features
