Netis E1+ User Manual

netis Wireless N Range Extender Quick Installation Guide
Step 4. Select your network of the main router (For example: netis vpn).
Step 5. Type in wireless password of the main router and click “Connect”
to setup your Wi-Fi Extender network.
Wireless Network: netis vpn
Password
Cancel Cannect
Select the Wireless Network to Extend
Roaming
netis vpn
WIFI403
WIFI-410
WIFI-407
netis
Model No.:E1+ Firmware Version:V1.2.31730
Manually Set WPS Button
Http:// www.netis-systems.com E-mail: support@netis-systems.com
6

Netis E1+ Specifications

General

Wireless Standard	IEEE 802.11b/g/n
Frequency	2.4GHz
Data Rate	Up to 300Mbps
Ports	1x 10/100Mbps Ethernet Port
Operating Temperature	0°C~40°C
Storage Temperature	-40°C~70°C
Operating Humidity	10%~90% non-condensing
Storage Humidity	5%~90% non-condensing
Antenna	2 x external antennas
Button	Reset
LED Indicator	Power
