NetZero FLA Series - TV and AC INSTALLATION

11
4 TV and AC INSTALLATION
A TV can be installed above the burner enclosure by following the methods shown below.
Single-Sided, Left-Corner, Right-Corner and Three-Sided Installations
See-Through and Peninsula Installations
If an air conditioning vent or fan is located near the burner the vent or fan must be positioned to blow away from the
burner.
min. 36 in
min. 2 in
min. 36 in
min. 2 in
min. 42 in
min. 30 in
min. 2 in
min. 30 in
min. 2 in
AC
