1.3 Locating the Burner
- Do not move or relocate the appliance while in use.
- For indoor use and in housing only. Minimum temperature of use is 50°F (10°C).
- No heat-sensitive or flammable objects can be placed within a 40 inch radius from, or directly above, the burner.
- Do not place any objects on the top of the burner except attached accessories.
- For service purposes, the surrounding area must allow for easy removal of the burner.
- Keep children, animals, and unauthorized persons at a safe distance at all times and never leave them unsupervised
when the appliance is on or hot.
- A Class B fire extinguisher must be located in close proximity to the appliance in case of fire.
1.4 Ventilation & Required Room Size
Open fires consume oxygen. Use only in well-ventilated areas and those that are protected from the draft effects of
cross ventilation. When selecting a location for the appliance it is important to consider the recommended minimum
room sizes and clearances to walls and combustible materials (see Table A). An air exchange rate of 1/hour is
recommended.
In a house of typical construction, that is, one that is not of unusually tight construction due to heavy insulation and
tight seals against air infiltration, an adequate supply of air for combustion and ventilation is provided through
infiltration. The unvented decorative appliance should be installed in a room where at least 200 ft.
3
(5.7 m
3
) of air
space is provided for each 1,000 BTU per hour of unvented decorative appliance rating (at maximum burner
adjustment). See Table A for recommended minimum room size.
If the burner is installed in a room smaller than the recommended minimum room size, or in a home of unusually tight
construction, the door(s) to adjacent room(s) should be kept open or a window to the outside should be opened at
least 1 inch (25.4mm) to guard against potential buildup of indoor air pollution.
The decorative appliance may only be installed in a bathroom or bedroom if the room meets the recommended
minimum room size.
1.5 Specifications
Table A
Burner
Fuel Capacity
Heat Output
MAX
Minimum Room
Size*
Approx. fuel
consumption on
MAX setting
Approx. fuel
consumption on
MIN setting
Approx. burn time on
MAX setting – MIN
setting
Gallon - (Liter)
BTU/h
ft
3
– (m
3
)
gal/h – (L/h)
gal/h – (L/h)
[h]
NZ40B
3.5 - (13.2)
24,000 – 10,000
4,800 – (136)
0.29 – (1.1)
0.12 – (.46)
12 – 29
NZ48B
4.5 - (17.0)
29,000 – 12,500
5,800 – (164)
0.35 – (1.3)
0.15– (.58)
13 – 30
NZ60B
5.5 - (20.8)
38,000 – 17,000
7,600 – (215)
0.46 – (1.7)
0.21 – (.78)
12 – 27
NZ72B
7.1 - (26.9)
51,000 – 21,000
10,200 – (289)
0.62 – (2.3)
0.26 – (.97)
11.5 – 28
NZ90B
9.6 - (36.3)
72,000 – 26,500
14,400 – (408)
0.88 – (3.3)
0.32 – (1.2)
11 – 30
NZ108B
12.1 - (45.8)
94,000 – 32,200
18,800 – (532)
1.14 – (4.3)
0.39 – (1.5)
11 – 31.5
1.6 Electrical Requirement
Burners NZ40B, NZ48B, NZ60B, and NZ72B must be connected to a dedicated 115V min.15-amp circuit. Burners NZ90B
and NZ108B must be connected to a dedicated 115V min. 20-amp circuit. A junction box for hardwiring the burner
must be located in the enclosure under the burner. This is shown in the clearances and installation section of this
manual.
1.7 Fueling
Do not use gel or thick fuels. Only use fuels consisting of 86-96.6% ethanol
(not dehydrated) by volume. NetZero Fuel is recommended.
