28
Appendix (
Segment Timer
)
EXAMPLE
For a typical Soccer application:
A. Main clock counts up.
B. Total length of game is 90 minutes.
C. Clock stops and horn sounds at end of first half (45 minutes).
D. Second half resumes with clock starting at 45 minutes.
E. When clock reaches 90 minutes, clock stops and horn sounds.
Make the following settings:
1. Press
SET ---
then
OPTIONS
.
2. Answer questions as desired.
3. When the control asks ---
ENABLE SEGMENT TIMER?
--- (Press
Yes
).
4.
[ SEG 01 MM:SS ]
(Press 4
,
press
5).
(45 minutes).
5.
[ SEG 01 45:SS ]
(Press
Yes
). NOTE: Only significant digits are required.
6.
ADD ANOTHER SEGMENT?
(Press
No
).
7.
DISPLAY SEGMENT TIMER ON SCOREBOARD?
(Press
No
).
8.
STOP TIME AT EACH SEGMENT?
(Press
Yes
).
9.
CHANGE DIRECTION OF MAIN CLOCK?
(Press
Yes
).
10.
CLOCK TO STOP AT SPECIFIED TIME?
(Press
Yes
).
11.
[ SET MM:SS ]
(Press
9
). (90 minutes).
12.
[ SET 9M:SS ]
(Press
Yes
). NOTE: Only significant digits are required.
13. Answer the remaining questions as desired and return to normal operating mode.
14. To set the period to 1 --- (Press
SET
then
TIME
then
NO
) --- this will leave the time unchanged (0:00)
up count ---- the display will show
[ PERIOD 0 ]
( press
1
).
The control will show
[ 0:00 UP ]
NOTE: This would be a good place to set a BOOKMARK. (Saves current configuration for quick start up)
When the first half ends --- the clock will stop and the segment horn will sound.
To get ready for the second half --- (Press
SET
then
TIME
then
NO
) --- this will leave the time unchanged,
45:00 ---- the display will show
[ PERIOD 1 ]
(Press
2
).
The control will show
[ 45:00 UP ]
To start the second half --- ( Press
TIME ON
). NOTE: If you are using the hand held switch, turn it off then on.
When the game time expires, the clock will stop and the horn will sound.
