88 Series Outboard / 8801 Issue 7.3
Fuse
The removable fuse holder houses a 1.6 AT fuse.
Power DIN socket
The 8 pin DIN socket should only be used to connect the power supply
provided with the 8801 unit.
NB:
For technical reasons the orientation of the socket is the opposite way up,
and the “top” of the DIN connector will therefore be underneath.
It is not possible to connect the plug the wrong way up.
