13
When power is restored, the instrument will recall the last control settings used.
Second, the user may utilize one of nine programmable instrument set-ups.
To store an instrument set-up press the Set key until STORE is lit. Then, use
the up arrow and down arrow keys to select instrument set-ups 1-9. Press the
left arrow or right arrow key to store the instrument’s settings at the selected
instrument set-up. The display will blink to indicate that the storage process
is complete. Location 0 is reserved for the factory default settings: 42/30
wheel, internal sync, normal mode, 84 Hz, IEEE address 12.
RECALL The user may recall instrument set-ups in one of two ways. First,
the control unit will retain the control settings when the power is removed.
When power is restored, the instrument will recall the last control settings
used.
Second, the user may utilize one of ten programmable instrument set-ups. To
recall a previously stored instrument set-up, use the up arrow and down
arrow keys to select instrument set-ups 0-9. Press the left arrow or right arrow
key to recall the selected instrument set up. The display will blink when the
recall process is complete. Location 0 is reserved for the factory default set-
tings.
Default settings Recalling set-up ‘0’ will restore the instrument to the
factory default settings: 42/30 wheel, internal sync, normal mode, 84 Hz,
IEEE address 12.
IEEE The user may select the Model 3501’s device address on the IEEE-488
bus. The factory default setting is 12. Use the up arrow or down arrow key to
change the device address.
Measure
The Measure key selects which frequency measurement—OUT1, OUT2,
F
outer
or F
sync
—is displayed on the front panel. The instrument will contin-
ue to measure and update the display until another function key is pressed.
