25
MEM* Accesses instrument set-up memory. 0 - Store, 1 - Recall. Use
with STO and RCL commands.
MOD*? Selects the instrument mode. 0 - H/S, 1 - +/-, 2 - NORMAL.
MSK[ ]? Enables condition required for SRQ (service request).
Bit 0 - Unlock, Bit 1 - Data Ready.
OSC[ ]? Sets the synthesizer frequency to three significant digits.
(4.00 Hz - 99.9 kHz in EXT mode; range automatically
limited in INT mode).
PHS[ ]? Sets the phase delay (-180.0 - +179.0).
RCL[ ]? Selects instrument set-up for recall (0-9). 0 - factory default
set-up. Use with MEM1 command.
SET* Selects the parameter modified by the arrow keys:
0 - Oscillator frequency, 1 - Phase, 2 - Harmonic multiplier,
3 - Subharmonic divide ratio, 4 - Recall set-up,
5 - Store set-up, 6 - GPIB device address.
STA? Returns status register. Bit 0 - Unlock, Bit 1 - Data Available.
The same information is available during a Serial Poll.
STO[ ]? Selects instrument set-up for storage (1-9). Use with MEM0
command.
SUB[ ]? Sets subharmonic divide ratio S (1 - 15).
WHL*? Selects the wheel. 0 - 60 slots, 1 - 42/30 slots, 2 - 7/5 slots,
3 - 2 slots.
