44
The power entry module requires two 5x20 mm, slow-blow fuses, such as
Littlefuse’s
®
Slo-Blo
®
239 series: one for the hot line and the other for the
neutral line. Replacement fuses should be as follows:
AC V
oltage Fuse Rating Littlefuse
100 V AC 0.4 A 239.400
120 V AC 0.4 A 239.400
220 V AC 0.2 A 239.200
240 V AC 0.2 A 239.200
Figure 7
Power entry module for the Model 3501 Optical Chopper.
