7 - MAINTENANCE

Fluids and lubricants

Lubricant

Type and Description

Engine Oil

API CJ-4

ENGINE OIL FULL SYNTHETIC SAE 0W-40

HYDRAULIC TRANSMISSION OIL - PREMIUM

Transmission/Hydraulic Oil

Front Axle/Gear Oil HYPOID GEAR OIL EP SAE 80W-90

Grease MULTI-PURPOSE GREASE EP / AW / NLGI 2

Coolant

Ethylene Glycol Coolant: 50%, water, / 50% anti-freeze

7-10

Table of Contents2
General Information9
Note to the Owner9
Tractor Intended Use10
Emissions Overview12
Electro-Magnetic Compatibility (EMC)15
Manual Scope16
Product Identification Number (PIN)18
Product Identification Number (PIN) Roll-Over Protective Structure (ROPS)20
Operator's Manual Storage on the Machine - Roll over Protective Structure (ROPS)21
Operator's Manual Storage on the Machine - Cab21
Machine Orientation - Roll over Protective Structure (ROPS)22
Machine Orientation - Cab23
Safety Information25
Safety Rules and Signal Word Definitions25
Safety Rules26
Do Not Operate Tag34
Folding Roll over Protective Structure (ROPS)35
Starting up the Machine Safely36
Stopping the Machine Safely41
Ecology and Environment42
Safety Signs - Cab43
Safety Signs - Roll over Protective Structure (ROPS)57
Instructional Signs - Cab72
Instructional Signs - Roll over Protective Structure (ROPS)81
Controls and Instruments91
Access to Operator's Platform91
Operator's Platform Access - Roll over Protective Structure (ROPS)91
Operator's Platform Access (Cab)92
Cab Side Window93
Cab Rear Window93
Operator's Seat94
Operator's Switch - Location and Function94
Seat Belt - Cab95
Seat Belt - Roll over Protective Structure (ROPS)96
Seat Controls - Cab - Suspension Seat97
Seat Controls - Roll over Protective Structure (ROPS)99
Forward Controls100
Component Location - Cab100
Component Location - Roll over Protective Structure (ROPS)101
Component Location - Mechanical Transmission102
Component Location - Hydrostatic Transmission (HST)103
Instrument Panel104
Engine Fault Code Display109
Cruise Control116
Transmission Shuttle Shift Lever117
Clutch Pedal118
Brake Pedals119
Foot Throttle Pedal119
Hand Throttle Lever120
Horn Switch121
Hazard Light Switch122
Power Take-Off (PTO) Switch123
Key Switch124
Differential Lock Pedal125
Hydrostatic Transmission (HST) Foot Pedals126
Tilt Steering Lever127
Multifunction Light Switch128
DPF Switch128
Beacon Switch (Beacon Is Optional)129
Left-Hand Side Controls130
Left-Hand Controls - Cab130
Transmission Range Lever - Mechanical Models132
Power Take-Off Gear Lever (Optional)133
Front Wheel Drive (FWD) Lever - Cab134
MID Power Take off (PTO) - Handle (Optional)136
Ground Speed PTO (GSP) Lever (Optional)137
Right-Hand Side Controls138
Right-Hand Controls - Cab138
Left-Hand / Right-Hand Controls - Roll over Protective Structure (ROPS)140
Parking Brake - Cab142
Parking Brake - Roll over Protective Structure (ROPS)143
Engine Speed Management (ESM) Switch - Roll over Protective Structure (ROPS)144
(Rops)144
Engine Speed Management (ESM) Switch - Cab146
Engine Speed Management (ESM) Up/Down Switch - Cab147
Hydraulic Power Lift (HPL) - Cab148
Hydraulic Power Lift (HPL) - Roll over Protective Structure (ROPS)149
Draft Control - Cab (Optional)150
Draft Control - Roll over Protective Structure (ROPS) (Optional)151
Rear Remote Control Valves - Cab152
Rear Remote Control Valves - Roll over Protective Structure (ROPS)153
MID Mount Two Spool Control Valve - Cab154
MID Mount Two Spool Control Valve - Roll over Protective Structure (ROPS)156
Transmission Main Shift Lever - Cab158
Transmission Main Shift Lever - Roll over Protective Structure (ROPS)158
Transmission Range Lever - Hydrostatic (HST) - Cab159
Transmission Range Lever - Hydrostatic (HST) - Roll over Protective Structure (ROPS)3-69159
Cab Internal Lighting160
Cab External Lighting161
Front Window Wiper/Washer162
Rear Window Wiper/Washer (Optional)163
Auxiliary Power Outlet164
Overhead Controls165
Cab Climate Control165
Air Conditioning166
Front Sun Shade170
Rear-View Inside Mirror170
Exterior Controls171
Rear-View Outside Mirrors171
Hood Release Latch171
Operating Instructions173
Commissioning the Unit173
Engine Speed Management (ESM) - Cab173
Engine Speed Management (ESM) Roll over Protective Structure (ROPS)175
Changing Tire Rolling Circumference and Vehicle Speed - Procedure177
Engine Break-In Procedure179
Diesel Particulate Filter (DPF) Regeneration180
Power Take off (PTO) - Operation - Cab185
Power Take-Off (PTO) - Operation - Roll over Protective Structure (ROPS)187
Three-Point Linkage189
Attaching Three-Point Equipment190
Extendable Drawbar - Cab194
Extendable Drawbar - Roll over Protective Structure - (ROPS)195
Top Link Adjustment196
Hydraulic Power Lift (HPL) Drop Rate Control Valve196
Roll over Protective Structure (ROPS) Fold Up/Down197
Roll over Protective Structure (ROPS) - CAB199
Starting the Unit201
Key Switch201
Cold Starting Aids202
Starting the Engine (Mechanical)203
Starting the Engine (Hydrostatic Transmission)206
Starting the Tractor with Jumper Cables209
Stopping the Unit210
Stopping the Engine210
Emergency Stopping - Cab211
Emergency Stopping - Roll over Protective Structure - (ROPS)212
Brakes - HST and Mechanical Transmissions213
Steering Wheel Adjustment216
Steering Operation217
Transmission Operation at Low Ambient Temperatures218
Hydrostatic Transmission (HST) Operation219
16X16 Mechanical Transmission - Operation - "H" Pattern221
Parking the Unit223
Brakes and Controls - Park - Cab223
Brakes and Controls - Park - Roll over Protective Structure - (ROPS)225
Transport Operations227
Road Transport227
External Lighting - Cab227
External Lighting - Roll over Protective Structure - (ROPS)228
Hazard Warning Light Operation - Cab229
Hazard Warning Light Operation - Roll over Protective Structure - (ROPS)230
Turn Signal Operation - Cab231
Turn Signal Operation - Roll over Protective Structure (ROPS)232
Road Lights - Operation - Cab233
Road Lights Operation - ROPS234
Work Lights - Operation - Cab235
Work Lights - Operation - Roll over Protective Structure (ROPS)235
Driving the Vehicle236
Shipping Transport237
Carrying the Tractor on a Transporter237
Recovery Transport237
Towing237
Working Operations239
General Information239
Roll over Protective Structure (ROPS) Fold Up/Down239
Tractor Ballasting240
Tractor Ballasting Weights242
Liquid Ballast244
General Information245
General Specification - Diesel Fuel247
General Specification - Biodiesel Fuels248
Refueling the Tractor - Cab250
Refueling the Tractor - Roll over Protective Structure (ROPS)251
Change Engine Coolant to Organic Acid Technology (OAT) Coolant252
Fluids and Lubricants254
Capacities255
Maintenance Planning256
Maintenance Chart256
Prior to Starting the Engine260
External Lighting System - Check for Damage260
Engine Compartment - Check261
Tire Pressure and Wheel Hardware Torque262
Brake and Clutch Operation - Check263
Instrument Panel and Indicator Lights - Prior to Starting the Engine264
Front Panel Warning Light Indicator - Check264
Every 10 Hours or Daily264
Engine Oil Level - Check264
Engine Cooling System - Check266
After First 50 Hours267
Engine Oil and Oil Filter - Change267
Hydraulic Oil Filter - Replace269
Hydraulic (HST) Oil Filter - Replace269
Wheel Bolt / Nut - Tighten270
Fuel Filter Water Separator - Replace270
Every 50 Hours271
Grease Fittings271
Transmission Fluid Level - Check272
Clutch Pedal Free Play - Check273
Brake Pedal Free Play - Check274
Hydrostatic Transmission (HST) Neutral Adjustment - Check274
Engine Belts - Check275
Wheels and Tires Pressure - Check276
Front Axle and Differential Oil Level - Check278
Air Cleaner - Clean - Primary Element279
Cab Air Filter - Clean280
Every 100 Hours282
Fuel Filter - Drain282
Every 300 Hours283
Engine Oil and Oil Filter - Change283
Hydraulic Oil Filter - Replace283
Hydrostatic Transmission (HST) Oil Filter - Replace283
Engine Belts - Check283
Wheel Bolt / Nut - Check283
Air Cleaner Primary Element - Replace283
Every 500 Hours284
Fuel Filter Water Separator - Replace284
Cab Air Filter - Replace287
Every 600 Hours289
Front Axle Differential Fluid - Change289
Transmission Fluid - Change291
Every 1000 Hours292
Air Cleaner Inner Element - Replace292
Every 1500 Hours293
Engine Coolant - Draining and Flushing - Cab293
Engine Coolant - Draining and Flushing - Roll over Protective Structure (ROPS)295
General Maintenance297
Fuel Water Separator Filter - Bleed297
Hydrostatic Transmission (HST) Neutral Adjustment299
Engine Belts - Adjust300
Battery301
Alternator302
Headlight Bulb303
Rear Tail/Brake/Hazard/Turn Signal Bulbs304
Front Turn Signal/Hazard Light Bulb305
External Work Light - Cab306
Wheels Bolt/Nut308
Front Wheels Toe-In309
Adjusting Steering Angle310
Brake Pedal Free Play - Check311
Clutch Pedal Free Play - Check311
Fuse and Relay Locations312
Storing the Tractor315
Removal of the Tractor from Storage316
Troubleshooting317
Symptom(S)317
Engine - Troubleshooting317
Clutch - Troubleshooting318
Mechanical Service Brakes - Troubleshooting318
Hydraulic Lift System - Troubleshooting318
Steering - Troubleshooting319
Hydrostatic Transmission - Troubleshooting319
Electrical System - Troubleshooting320
Specifications321
Wheel Tread Settings321
Tire Pressures and Rolling Circumferences, Rated Capacities and Speeds322
General Specification323
Consumables330
Tractor Dimensions - Cab331
Tractor Dimensions - Roll over Protective Structure (ROPS)333
10 - Accessories335
Optional Equipment335
Safety Devices336
Forms and Declarations337
Pre-Delivery Report - Dealer's Copy337
Pre-Delivery Report - Owner's Copy339

New Holland Boomer 55 User Manual
