7 - MAINTENANCE
Hydrostatic Transmission (HST) neutral adjustment
WARNING
Rotating parts!
Keep clear of all drives and rotating components.
Failure to comply could result in death or serious injury.
W1101A
WARNING
Crushing hazard!
DO NOT work under a machine supported by a jack alone.
1. Park the machine on a level surface.
2. Block the wheels.
3. Support the machine with safety stands.
Failure to comply could result in death or serious injury.
W1508A
CAUTION
Hot area!
Use care when working near hot components. Wear protective gloves.
Failure to comply could result in minor or moderate injury.
C0034A
Check neutral adjustment
1. Raise the rear of the machine up and support with
safety stands.
2. Block the front wheels.
3. Remove the rear wheels.
4. Have a helper perform the following procedure:
1. Start the machine.
2. Release the parking brake.
3. Disengage the four wheel drive.
4. Place the range lever in high range.
5. Move the throttle to full throttle.
6. Operate the machine in forward and allow the ped-
als to return to the neutral position.
7. Operate the machine in reverse and allow the ped-
als to return to the neutral position.
8. Perform the steps 6 and 7 multiple times to ensure
a consistent result.
5. The rear hubs should stop moving when the operator
allows the pedals to return to the neutral position. If the
rear hubs move or creep, go to step 6.
7-55
