Newco FKP-4 - Pod Brewing Mechanism Assembly Details

15

ITEM # PART NUMBER DESCRIPTION QTY/EA
1 780230 BREW MECH MOTOR 2
2 780231 DELTROL SOLENOID 1
3 780587 LOWER BREW CHAMBER UNIVERSAL 2 1
4 773246 U-CUP SEAL RING 1
5 780539 CHAMBR UP,I/H,BR,56&61MM 1
6 780554 EJECT SLOPE CAM ASS’Y 1
7 780588 MOLDED BUMP DISC PAD 1
9 780546 KICKER SLIDE WASHER 1
10 780536 ¼” X 1” STAINLESS STANDOFF SPACER 1
11 780541 COMPRESSION SPRING 1
12 780264 LOWER BREW CHAMBER O-RING 1
13 780096 GUTTER, BREW MECH 1
POD BREWING MECHANISM
780585
