Newco FKP-4 - Tank Assembly Components Overview

16

ITEM # PART NUMBER DESCRIPTION QTY/EA
1 110958 RELAY, 12 VDC SPST 30A 1
2 111593 HI-LIMIT THERMOSTAT 1
3 109937 GEAR PUMP ASS’Y 1
4 781772 PUMP ASS’Y W/ELBOW (HOT WATER) 1
5 780253 TANK ONLY 1
6 773056 AIR PUMP, POD 1
7 500396 LIQUID LEVEL PROBE& BUSHING 2
8 151677 DUAL TEMP THERM PROBE 1
9 100149 ELBOW ¼ C X 1/8 NPT 1

10
704166-10 (1700W)
704161-10 (1400W)
TANK HEATING ELEMENT (US)
TANK HEATING ELEMENT (CAN)
1
11 120682 FLOWMETER 1
12 767281 “WYE” HOSE FITTING 1
13 202165 AIR PUMP CHECK VALVE 1
14 202166 WATER PUMP CHECK VALVE 1
15 780748 HEX SPACER (FOR AIR PUMP NOT SHOWN) 1
16 780749 CLAMP, LOOP, VIBRAT DAMP (NOT SHOWN) 1
TANK ASS’Y
780619
