Newmac CL 86-96C - Combination Furnaces

1
COMBINATION FURNACES
MODELS CL 86-96C, CL 86-96G, CL115-170C, CL 115-170G
It is the responsibility of the consignee of the unit to examine the packages for damages, and if found, to note the same on the
Carrier’ Bill of Lading.
PACKAGE # 1 – Heat exchanger with end panels and side panel installed, filters, draft regulator, accessory carton, brick rack, if
brick liner, in firebox. CL 115-170G have 5 grates, 9 liner pieces and 1 shaker handle in firebox. CL 86-96G have 3 grates, 6
split brick and shaker handle in firebox, CL 86-96C have 8 split brick in firebox.
PACKAGE # 2 – Blower section with blower installed, blower belt attached.
PACKAGE # 3 – Oil Burner box with oil burner, primary relay, cell and nozzle.
PACKAGE # 4 – Firebrick CL 86-96C – 20 full brick
CL 86-96G – 20 full brick
CL 115-170C – 30 full brick
Accessory Carton – Wire harness, fan limit control, solid fuel and oil burner thermostats, junction box with relay transformer
mounted, blower motor and pulley, draft fan package, Instruction Manual.
FIG. 1 - GENERAL INSTRUCTIONS
MODEL
AERO
BTUH
INPUT
BTUH
OUTPUT
NOZZLE
PUMP (p.s.i.)
INSERTION
CL86
F-AFC-2-8
105,000
86,000
.75 (80 R)
100
7-7/8”
CL96
F-AFC-2-8
119,000
96,000
.85 (80 R)
100
7-7/8”
CL115
F-AFC-3-8
140,000
111,000-109,000
1.00 (80 R)
100
7-7/8”
CL140
F-AFC-3-8
175,000
140,000-138,000
1.25 (80 R)
100
7-7/8”
CL155
F-AFC-3-8
189,000
152,000-150,000
1.35 (80 R)
100
7-7/8”
CL170
F-AFC-3-8
210,000
169,000-168,000
1.50 (80 R)
100
7-7/8”
MODEL
BECKETT
BTUH
INPUT
BTUH
OUTPUT
NOZZLE
PUMP (p.s.i.)
INSERTION
CL86
SR81RD (NM201)
105,000
86,000
.75 (70 A)
100
7-7/8”
CL96
SR81RD (NM201)
119,000
96,000
.85 (70 A)
100
7-7/8”
CL115
SR81RF (NM202)
140,000
111,000-109,000
1.00 (70 A)
100
7-7/8”
CL140
SR81RF (NM202)
175,000
140,000-138,000
1.25 (70 A)
100
7-7/8”
CL155
SR81RF (NM202)
189,000
152,000-150,000
1.35 (70 A)
100
7-7/8”
CL170
SR81RF (NM202)
210,000
169,000-168,000
1.50 (70 A)
100
7-7/8”
CL86
AFG (NM502)
105,000
86,000
.75 (70 A)
100
7-7/8”
CL96
AFG (NM502)
119,000
96,000
.85 (70 A)
100
7-7/8”
CL115
AFG (NM503)
140,000
111,000-109,000
1.00 (70 A)
100
7-7/8”
CL140
AFG (NM503)
175,000
140,000-138,000
1.25 (70 A)
100
7-7/8”
CL155
AFG (NM503)
189,000
152,000-150,000
1.35 (70 A)
100
7-7/8”
CL170
AFG (NM503)
210,000
169,000-168,000
1.50 (70 A)
100
7-7/8”
MODEL
RIELLO
BTUH
INPUT
BTUH
OUTPUT
NOZZLE
PUMP (p.s.i.)
INSERTION
CL96
40 F3 (10” BT)
111,000
94,000
0.65 (60W)
150
7-1/2”
CL96
40 F3 (10” BT)
111,000
94,000
0.65 (AB)
150
7-1/2”
CL96
40 F3 (10” BT)
119,000
101,000
0.75 (60W)
130
7-1/2”
CL115
40 F5 (10” BT)
140,000
111,000-109,000
0.85 (60 W)
150
7-1/2”
CL140
40 F5 (10” BT)
175,000
140,000-138,000
1.00 (60 W)
150
7-1/2”
CL155
40 F5 (10” BT)
189,000
152,000-150,000
1.10 (60 W)
150
7-1/2”
