Newmac CL 86-96C - Gas Burner Information; Burner Specifications and Installation

22
BURNER SPECIFICATIONS FOR NEWMAC FURNACES ***
Gas Orifice
Gas Orifice
Furnace
Model
No.
B.T.U.H.
Output
Aero
Oil Burner
Model No.
Nozzle
Oil -
gph
Input
Oil
B.T.U.H.
Aero*
Gas Burner
Model No.
L. P.
Nat.
Input
Gas
B.T.U.H.
Adams**
Gas Burner
Model No.
L. P.
Nat.
CL 86C-86G
86,000
F-AFC-2-8
.75 (80°)R
105,000
PGB-220
#23
#7
105,000
HP 225B-PS
#33
ADJ.
CL 96C-96G
96,000
F-AFC-2-8
.85 (80°)R
119,000
PGB-220
#20
7/32"
120,000
HP 225B-PS
1/8"
ADJ.
CL 115C-115G
111,000
F-AFC-3-8
1.00 (80°)R
140,000
PGB-220
#15
15/64"
145,000
HP 225B-PS
#29
ADJ.
CL 140C-140G
140,000
F-AFC-3-8
1.25 (80°)R
175,000
PGB-220
#7
1/4"
170,000
HP 225B-PS
#25
ADJ.
CL 155C-155G
152,000
F-AFC-3-8
1.35 (80°)R
189,000
PGB-220
#5
17/64"
185,000
HP 225B-PS
#24
ADJ.
CL 170C-170G
169,000
F-AFC-3-8
1.50 (80°)R
210,000
PGB-220
#2
9/32"
200,000
HP 2258-PS
5/32"
ADJ.
* Aero Gas Burner Model #PGB-220 must operate at 3.0" W.C. for natural gas and 3.5" W.C.
for propane gas.
** Adams Gas Burner Model #HP 2258-PS must operate at 3.5" W.C. for natural gas and 11.0"
W.C. for propane gas. LP burners are designated by "LP". Example HP 2258-LP-PS.
*** Newmac furnaces are not certified in Canada with gas burners installed. Check with local
authorities and obtain their approval before installing a power gas burner.
Refer to gas burner manual for proper installation and service.
GAS BURNER INSTALLATION
GAS PIPING
All piping must comply with local codes and ordinances. Refer to the gas burner manual for further
recommendations.
BURNER MOUNTING
Install burner on the burner mounting plate with blast tube flush with the outside wall of the combustion
chamber. Connect the gas line to the burner by means of a union.
WIRING OF BURNER
Connect wiring according to Fig. 16-1A for the Adams burner and Fig. 16-1B for the Aero burner.
FIG. 16-1A
WIRING DIAGRAM FOR INSTALLATION
OF ADAMS GAS BURNER
FIG. 16-1B
WIRING DIAGRAM FOR INSTALLATION
OF AERO GAS BURNER
