AERO PGB 220-370 GAS BURNER PARTS LIST
ITEM # PART NAME & DESCRIPTION AERO #
1 F Housing 9035222400
2 Airtube (5"-8"-11')
3 Mounting Flange (Standard) 2735161000
4 Micro Switch (V3101-D8) 9035061441
5 Sail & Leaf (JV-26) 2735121091
6 "J" Box 2735121091
7 "J" Box Hardware 2735121091
8 Motor (1/7/3450/60/1) 2735251414
9
Fan 524-202 (PGB 220) 2735151200
Fan 524-316 (PGB 370) 2735152016
10 Raceway 2726202550
11 Air Band Assembly 2726200100
12 Ignition Control 9035061311
* Wiring Harness 9035061321
14 High Voltage Cable 9035061301
15 Fan Center 9035061210
16 Fuse Assembly 9026121400
17
Manifold Assembly - 1/2" PGB 220
Manifold Assembly - 3/4" PGB 370
18 Electrode Assembly (S.S.B.) 9026121300
19 Centering Bolt 9035202205
20 Orice (Input Required) 7235515220
21
Replaced by Gas Valves22
23
24
Combination Gas Valve (220) 9035061225
Combination Gas Valve (370) 9035061227
Comb. Propane Valve (220/370) 9035061226
* Adjustable Flange 2735162000
* Base assembly 2735032000
* Carton - complete 9035401000
* NOT SHOWN
Figure. 17-1F - AERO PGB 220-370 GAS BURNER PARTS LIST
