• Section 3 provides information about the Principles of Operation of the
Model 1815-C.
• Section 4 provides for Test, Maintenance and Adjustment of the Model
1815-C.
• Section 5 provides instructions for obtaining Factory Service.
All Model 1815-C Optical Power Meters are carefully assembled, tested, and
inspected before shipment. Upon receiving this instrument, check for any
obvious signs of physical damage that might have occurred during shipment.
Report any such damage to the shipping agent immediately. Retain the
original packing materials in case reshipment becomes necessary.
The Model 1815-C Optical Power Meter should have some operations per-
formed before measurements are made. These include:
• Connection and calibration of the detector (Section 2.4.3 and 2.4.4)
The following table describes the accessories and services available for use
with the Model 1815-C Optical Power Meter. Refer to Figure 1 for where each
accessory fits within the Model 1815-C Optical Power Meter family tree. For
more information, please refer to the Newport Catalog.
Table 1 — Model 1815-C Compatible Detectors
Accessory Description
Low-Power Detectors
818-UV 0.25 to 1.1 µm, silicon, cylindrical with
detachable OD3 attenuator
818-SL 0.4 to 1.1 µm, silicon, cylindrical with
detachable OD3 attenuator
818-IR 0.78 to 1.8 µm, germanium, cylindrical with
detachable OD3 attenuator
818-ST 0.4 to 1.1 µm, silicon, wand detector with
integral insertable OD3 attenuator
High-Power Detectors
818T-10 10 W flat spectral response air cooled disk
thermopile
818T-30 30 W flat spectral response air cooled disk
thermopile
818T-150 150 W flat spectral response air cooled disk
thermopile
818T-150X 150 W flat spectral response air cooled
eximer optimized disk thermopile
818T-300 300 W flat spectral response water cooled
disk thermopile
Unpacking and
Inspection
1.3
Preparation for Use
1.4
Optional Accessories
and Services
1.5
