Pyrocam IV Operator’s Manual Document No. 50337-001 Rev F 2/21/2017 Page 5
CHAPTER 1 – GENERAL INFORMATION
1.1 Introduction
The Pyrocam IV is a high performance, solid-state, pyroelectric camera that features a
large 25mm imager (320 x 320 pixels) and 16-bit A/D converter. This enables reliable
measurement and analysis of both large signals and low-level signals in the wings of the
laser beam. The uniform infrared response and large dynamic range make the camera
suitable for real-time thermal imaging of hot sources. 16-bit digitizing also enables
accurate signal summing and averaging to pull weak signals out of noise. The Pyrocam
employs an IEEE 802.3ab Gigabit Ethernet interface that is compliant with the GigE Vision
standard. The camera ships with an Ethernet to USB 3.0 adaptor and a 10’ (3m) Ethernet
cable. If a longer or shorter cable is required, Spiricon recommends using a shielded Cat6A
cable.
The Pyrocam ships with BeamGage Standard software. The Pyrocam is also compatible
with National Instruments Vision Image Acquisition Software and any GenICam standard
client (CHAPTER 4).
1.2 Models
Spiricon offers the Pyrocam in the following models, all of which include BeamGage
Professional Edition.
Model
Description
PY-IV-C-A Pro
Pyrocam IV, CW and Pulsed operation*
PY-IV-C-A-MIR Pro
Pyrocam IV, CW and Pulsed operation, MIR enhanced*
* All Pyrocams are shipped without a window installed. Windows are available with A/R coatings for
specified wavelength ranges. For a list of available windows, see APPENDIX E.
WARNING:
There is no protective window on the Pyrocam and it can be easily
damaged by objects striking the detector, by particles getting inside the
package, or by ESD. Special care must be taken to keep the detector
clean.
If a window is purchased, follow the installation instructions in APPENDIX B.
1.3 Included Items
The standard Pyrocam models come with the following included items:
 Approved Gigabit to USB 3.0 adaptor
 Shielded Cat6A Ethernet cable, 10’ (3m)
 Wall mount universal power supply with international AC mains adapters
 SMA to BNC trigger cable, 36” (0.9m)
 Protective dust cover
 DVD with BeamGage software
