Pyrocam IV Operator’s Manual Document No. 50337-001 Rev F 2/21/2017 Page 27
APPENDIX A – SPECIFICATIONS
Pyrocam IV Specifications
ENVIRONMENTAL
Operating Temperature +5°C to +50°C
Storage Temperature -30°C to +85°C
Humidity 95% max non-condensing
POWER REQUIREMENTS
Line Voltage 100-240 Vac
Line Frequency 47-63Hz
Power Consumption 10W
WEIGHT
Pyrocam 1.20kg (2.65 lb.)
Power Supply 0.15kg (0.33 lb.)
Shipping 3.73kg (8.0 lb.)
DIMENSIONS
See page 29
GENERAL
Wavelength range 157nm to 355nm
1.06µm to >1000µm
Detector Array Details
# Elements 102,400… 320 x 320
Active Area 25.6mm x 25.6mm
Element Spacing 80µm x 80µm
Pixel Size 75µm x 75µm
Detector Material LiTaO
3
Interchangeable Windows See APPENDIX E
ADC 16 bit Chopped / 15 bit Pulsed
Memory 64MB RAM, 4MB Flash
Interface IEEE 802.3ab Gigabit Ethernet, GigE Vision compliant
Electronic Gain x1, x1.14, x1.33, x1.6, x2, x2.66, x4, x8
Chopper
1
2-blade helical design, 5.25” dia. PID controlled
