PPA5xx/15xx user manual
4-1
4 Using the menus
The PPA5xx/15xx range are very versatile instruments
with many configurable parameters. These parameters are
accessed from the front panel via a number of menus.
Each of the main menus may be accessed directly from a
specific key.
ACQU
data acquisition parameters such as speed
and filtering
COUPLING
select ac/dc coupling
RANGE
select input ranges, and scaling
DATALOG
specify datalog parameters
APP
Application specific functions
MATHS
User defined computations
ALARM
control of audible alarm
REMOTE
communications options (RS232 etc)
AUX
control of auxiliary devices connected to the
rear EXTENSION and AUX ports
SYSTEM
general system options such as phase
convention, keyboard beep etc.
MODE
function control
PROG
recall/store/ delete of programs and datalog
Each menu starts with the currently set parameters visible
but no cursor. In this condition, pressing the menu key
again or the HOME key aborts the menu operation and
reverts to normal operation.
To select any parameter, press the UP or DOWN key and a
flashing box will move around the menu selecting each
parameter. In this condition, the keys take on their
secondary function such as numbers 0-9 etc.
Pressing the HOME key reverts to the opening state where
the parameters are displayed but the cursor is hidden.
