PPA5xx/15xx user manual
10-1
10 Integrated power measurements
In the INTEG mode, the PPA5xx/15xx computes the
following additional values:
Parameter
Units
Watt hours
Wh
VA hours
VAh
VAr hours
VArh
Average power factor
Average rms voltage
V
Ampere hours
Ah
Fundamental watt hours
Wh
Fundamental VA hours
VAh
Fundamental VAr hours
VArh
Average fundamental power factor
Average fundamental voltage
V
Fundamental ampere hours
Ah
The integrator is started by pressing the START key; the
elapsed time is displayed in the upper left corner of the
display. The integration can be stopped by pressing the
STOP key then restarted by pressing the START key again.
To reset the accumulated values and time press the ZERO
key. While the integration is running, pressing the REAL
TIME key holds the displayed values but accumulation
continues in the background.
Once started, the integration continues to accumulate in
the background even if the MODE is changed to POWER or
RMS. This allows the real time values to be displayed
without disturbing the integration.
To make an integrated measurement over a specific
interval, an integration run time can be entered in hours
and minutes. The integration will automatically stop when
the integration timer reaches the value entered as if the
